Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Hex head bolts/screws provide extremely strong tapping performance.
Features
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
- Coating meets the special requirements of different applications (RoHS compliant).
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Thread Size | 0.625 mm (0.025 in) |
|---|---|
| Thread Size (Diameter × Pitch) | 5/8×11 mm |
| Class or Grade | SAE J429 Grade 8 (150 ksi) |
| Locking Feature | Nylon Patch |
| Thread Direction | RH |
| Bolt Length | 44.45 mm (1 3/4 in) |
| Bolt Type | Hex Head Bolt |
| Coating | Zinc Plated |
| Handle Length | 6.35 mm (0.25 in) |
| Material | Carbon Steel |
Compatible Equipment
- Motor Graders: 120, 140G
- Track Loaders: 816F
- Compactors: 815, 814, 816
- Dozers: D10N, D5H, D9L, D9R, D8L, D9N
- Excavators: 621G, 637G, 637E, 657G
- Off-Highway Trucks: 772G, 785D, 771D, 789D
- Asphalt Pavers: AD45, AD63
Additional information
| Machine Model | 120, 140G, 621G, 637E, 637G, 657G, 771D, 772G, 785D, 789D, 814, 815, 816, 816F, AD45, AD63, D10N, D5H, D8L, D9L, D9N, D9R |
|---|---|
| Equipment Type | Excavators, Track Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors, Asphalt Pavers |
| Part Source | Genuine OEM |
