Description
Cat® tube connection fittings meet the highest standards of quality and reliability. These parts are manufactured to tight tolerances to ensure leak-free connections. Every Cat tube connection fitting meets or exceeds applicable industry standards for working pressure, assembly torque capability and corrosion protection, keeping machines durable and up and running.
Features
- Fluid-conveying tube connection component
- Meets or exceeds industry-standard part performance and provides a leak-free connection
- The image provided is for reference only. The part construction may differ slightly from the image shown, but this part is interchangeable with the OEM part.
Applications
Tube connection fitting parts are compatible only with other parts designed for the same type and size of connection. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Thread Direction | RH |
|---|---|
| Material | Alloy Zinc |
| Drive Chain | 33.34 mm (1.313 in) |
| Thread Size | 1.000 mm (0.039 in) |
| Material Description | Plated Steel |
| Coating | None |
| Thread Size (Diameter × Pitch) | 1.000×14 mm |
| Class or Grade | None |
| Transmission and Hydraulic Oil Compatible Seals | 7J-9108 (1-14) |
| Thickness | 10.5 mm (0.413 in) |
| Oil and Fuel Compatible Seals | 228-7091 (1-14) |
| Coolant and DEF Compatible Seals | 6V-5138 (1-14) |
| Nut Model | Hex |
| Thread Size (in – TPI) | 1/1-14 in |
