Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Features
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
- Coating meets the special requirements of different applications (RoHS compliant).
Applications
Cat bolts form a high-performance system with mating washers and nuts to produce consistent, high clamping force. You can rely on Cat fasteners to help you build, maintain or rebuild – for most machine and shop applications around the world.
Specifications
| Thread Direction | RH |
|---|---|
| Hex Size | 25.4 mm (1 in) |
| Height | 8 mm (0.31 in) |
| Thread Size (Diameter × Pitch) | 11/16×16 mm |
| Thread Size | 0.6875 mm (11/16-16 in) |
| Drive Chain | 25.4 mm (1 in) |
| Thickness | 8 mm (0.315 in) |
| Nut Model | Hex Nut |
| Thread Size (in – TPI) | 11/16-16 in |
| Material | Alloy Zinc |
| Material Description | Steel |
Compatible Equipment
- Generator Sets: 3512B, 3512E, C7.1, G3516, 3516C, C4.4
- Track Loaders: 826K, 953, 826H, 994K, 963, 973K, 993, 972, 824G, 963D, 953K, 990K, 826G, 995, 953D, 834H, 963K, 816F, 992
- Cold Planers: PM620, PL83, PL61, PL87, TH360B, PM622, PL72, SE60 VT XW, SE50 VT
- Compactors: CB1.8, CB1.7, 834K, 824K, CB-534D, CB-14, CB-564D, 825K, 815, CW-16, CS-563E, CB-44B, CB-434D, CS-56, CW-34, CB16, 814, 816, CS12, CB-64B, CS-54, CB-66B, CS11, CS68B, CS56B, CS74B, CS12 GC, CB10, CB15, CB13, CS-54B, CS-533E
- Engines: C32
- Excavators: 330, 305, 349D, 307.5, 349D2, 390D L, 374F, 349D2 L, 390F L, 374D L, 320D2, 320D, 336D, 336D2, 305C CR, 303C CR, 326D2, 308E, 307E, 326D2 L, 329D2 L, 308D, 329D, 303.5E2 CR, 303, 329D2, 374, 349F L, 313 GC, 313, 330D L, 305E2 CR, 335, 313D2, 315F LCR, 621K, 325, 352, 314D LCR, 330 GC, 6015B, 6020B, 314D CR, 637K, 350, 336F, 315, 432, 120 GC, 326, 340, 323, 336, 333, 6060, 301.8, 395, 352F, 301.6, 6040, 305 CR, 6015, 637G, 315 GC, M325D L MH, 657G, 365B, 621G, 349D L, 345C, 345B, 365C L, 345D, 349E L VG, 416F2, 345C L, 3512C, 637E, 365C, 374F L, 345D L, 621H, 390F, 416E, 349E L, 390D, 336F L, 385C L, 385B, 385C, 345 GC, 320, 320 GC, 320D FM, 3508B, 349E, 336E L, 349, 302.7CR, 324D L, 324D, 311D LRR, 336D L, 320D L, 330GC, 312D, 312D L, 312E, 323D L, 312E L, 313F LGC, 320D3 GC, 365B L, 303CR, 303.5CR, 336 GC, 6030, 320 GX, SE60 V XW, 318D2, 313F L, 3101, 312D2, 320C, 325C, 325D, 318D2 L, 336F LN, 336E, 329E L, 325B L, 330 L, 325C L, 312C, 320D RR, 329D L, 320B, 330C, 336E LH, 336D2 L, 330D2, 314C, 330C L, 315D L, 325D L, 313D2 GC, 320D2 L, 311C, 336F L XE, 328D LCR, 313D, 312D2 L, 329E, 320E, 323D2 L, 336E LN, 313D2-GC, 312D2 GC, 330D, 336D2 XE, 315C, 312C L, 330D2 L, 335F LCR, 318D L, 320D2 GC, 325B, 323D, 312F, 320D GC, 330B
- Asphalt Pavers: AD30, AP655F, AP355F, AP655F L, AP-600D, AD45, AP300F
- Skid Steer Loaders: 249D3, 239D3, 299D3 XE, 24, 289D3, 259D3, 232D3, 226B, 232D, 226B3, 236B3, 216B3, 236, 246C, 313D2 LGP, 279C, 262C
- Motor Graders: 120, 14, 140 GC, 3606, 16M, 16M3, 18, 16, 140K, 160K, 12K, 316F, 120H, 14M, 12H, 140H, 16H
- Wheel Excavators: M315, M315GC, MD6200, IT14G, M320, M317D2, M315D, MD6250, M322D, M313D, M320D2, M315D2, MD6310
- Dozers: D6T, D8R, D8T, D7, D8, D4, D9T, D9R, D6N, D6T LGP, D6R II, D6K2, D7R II, D5K2 XL, D6R III, D7E, D5N, D5G, D3G, D10, D7R, D3K2 LGP, D4G, D6R XL, D6R, D11R, D11T, D10R, D10T2, D10N, D8N, D9N, D8L, D9L, D9, D11
- Compact Track Loaders: 299D3, 279D3
- Mini Excavators: 302CR, 301.5, 301.7CR, 306, 308, 307, 310, 305.5E, 303.5D, 305.5E2, 307D, 307C, 307E2, 303.5C, 303.5E, 303.5, 305E2, 307B, 308E2
- Wheel Loaders: 966L, 924K, M314, 950H, 972G, 980G, 938K, 980H, 966F, 988K, 950G, 966H, 972H, 986H, 988H, 992C, RM400, 910, R1700K, 966, 962G, R3000H, R1700G, 966K, 950L, RM500B, 834, 950 GC, 938M, 990H, 980L, R1700 XE, R2900 XE, 950, 962L, 836, 926M, 972L, R2900G, 988G, 924HZ, 928HZ, 992D, 906K
- Off-Highway Trucks: 793F, 730, 775G, 725, 797F, 798 AC, 735, 740 GC, 740, 745, 770G, 772G, 794 AC, 785, 796 AC, 793, 745C, 7495, 777, 777D, 793D, 773F, 725C2, 777E, 789D, 773D, 740B, 785D, 789, 773, 773E, 771D
