Description
:
Angle tube adapters change the direction of flow to different angles.
Features
Cat® angle tube adapters are designed to resist leaks and last in heavy-duty applications.
Recommended Applications:
Cat angle tube adapters are suitable for a wide range of hydraulic applications, from hydraulic oil systems to brake systems.
Specifications
| Hose Warning | Improper selection of hose and coupling combinations will void the warranty and may result in serious injury or death, property damage, or component and machine system failure. Cat® hose assembly products are designed and tested as a system to achieve reliable connections, maximizing hydraulic system safety and reliability. In addition, use of properly maintained, appropriate Caterpillar tooling is recommended to ensure hoses are crimped to specification. Using Caterpillar hose with another manufacturer's couplings, or Caterpillar couplings with another manufacturer's hose, may result in hose assemblies that are unreliable, unsafe or perform poorly. Caterpillar does not recommend or endorse this practice. For more information, refer to SAE J1273 Section 6.3 and ISO 17165-2 Section 6.3. |
|---|---|
| Material | Carbon Steel |
| Height | 43.18 mm (1.7 in) |
| Width | 68.58 mm |
| Length | 83.82 mm (3.3 in) |
| Coolant and DEF Compatible Seals | 415-2887 (1-7/16-12), 6V-5064 (1-5/16-12) |
| Oil and Fuel Compatible Seals | 228-7093 (1-7/16-12), 238-5084 (1-5/16-12) |
| Transmission and Hydraulic Oil Compatible Seals | 5K-9090 (1-7/16-12), 7M-8485 (1-5/16-12) |
