Description
O-rings are used for static sealing and some dynamic applications.
Features
Cat® O-rings are made from materials compatible with the fluids, temperatures and pressures in Cat engines and machines. These materials resist wear and extrusion, giving the seals excellent compression set resistance. In addition, some Cat O-rings are coated with PTFE to minimize seal twisting and cutting during installation.
Our O-rings are dimensioned to strictly follow tight tolerances, ensuring they are properly seated in the seal groove with the right seal compression.
With more than 2500 different sizes and materials of O-rings, Cat O-rings are the best solution for the O-ring needs of your Cat and other mobile equipment.
Cat sealing systems prevent leaks and contamination of more expensive parts. Genuine Cat seals protect your investment.
Applications
O-rings are used in many static and dynamic joints in Cat machines and engines.
Specifications
| Polymer | FKM (Fluorocarbon) |
|---|---|
| Compatible | Diester Lubricants; Halogenated Hydrocarbons (Above 100 Degrees C); Excellent Compression Set Resistant Material; Petroleum Fluids; Phosphate Ester Fluids; Silicone Oils; Certain Acids |
| Dash Size | 115 in |
| Material Hardness | 90A |
| Cross-Section Diameter | 2.62 mm (0.103 in) |
| Material | Fluoroelastomer (FKM) Rubber |
| Inside Diameter | 17.12 mm (0.674 in) |
Compatible Equipment
- Generator Sets: C4.4
- Track Loaders: 963K, 963D, 953D
- Cold Planers: PL72, PL87, PM620, PM622, PL83, PL61
- Wheel Excavators: M320, IT14G, M315, M313D, M322D, M320D2, M315D, M315D2, M317D2
- Compactors: CP12 GC, CB16, CS12, CB2.5 GC, CB2.7 GC, CS-533C, CB-534D, CB-434D, CS-563E, CB-24B, CB-66B, CS-583D, CB-34B, CB-564D, CS74B, CP56B, CW-34, CP11 GC, CS7, CC2.7 GC, CS12 GC, CS11, CC-34B, CS-56, CB2.7, CS54B, CB2.9, CS78B, CB-36B, CS68B, CS56B, CS79B, CB-64B, CB2.5, CP54B, CS-54, CB13, CB15, CB10, CS-54B, CS-533E, CS64B
- Dozers: D8T, D7E, D10T2, D9T, D6K2, D6N, D3G, D5G, D8R, D5K XL, D8N, D4G, D6R XL, D6R, D5K LGP, D4, D6R II, D6R LGP, D9, D8
- Excavators: 6040, 6060, 313F LGC, 637G, 6015, 657G, 6015B, 621G, 637E, 3508B
- Wheel Loaders: 906K, 988G, 910
- Asphalt Pavers: AP300F
Additional information
| Machine Model | 313F LGC, 3508B, 6015, 6015B, 6040, 6060, 621G, 637E, 637G, 657G, 906K, 910, 953D, 963D, 963K, 988G, AP300F, C4.4, CB-24B, CB-34B, CB-36B, CB-434D, CB-534D, CB-564D, CB-64B, CB-66B, CB10, CB13, CB15, CB16, CB2.5, CB2.5 GC, CB2.7, CB2.7 GC, CB2.9, CC-34B, CC2.7 GC, CP11 GC, CP12 GC, CP54B, CP56B, CS-533C, CS-533E, CS-54, CS-54B, CS-56, CS-563E, CS-583D, CS11, CS12, CS12 GC, CS54B, CS56B, CS64B, CS68B, CS7, CS74B, CS78B, CS79B, CW-34, D10T2, D3G, D4, D4G, D5G, D5K LGP, D5K XL, D6K2, D6N, D6R, D6R II, D6R LGP, D6R XL, D7E, D8, D8N, D8R, D8T, D9, D9T, IT14G, M313D, M315, M315D, M315D2, M317D2, M320, M320D2, M322D, PL61, PL72, PL83, PL87, PM620, PM622 |
|---|---|
| Equipment Type | Excavators, Wheel Excavators, Wheel Loaders, Track Loaders, Dozers, Compactors, Asphalt Pavers, Cold Planers, Generator Sets |
| Part Source | Genuine OEM |
