Description
Cat® clips and clamps are not ordinary off-the-shelf clips and clamps, but another excellent Cat "Built For It" product.
Features
- Cat clips and clamps are built to exact specifications and are durable, reliable and efficient
- Strength and quality – clips and clamps meet or exceed ANSI, ASTM, and DIN requirements
- Cat clips, clamps and fasteners work together as a system to provide outstanding reliability and safety for our customers.
- This part is ideal for stocking in small service shops and/or on field service vehicles.
- Coating meets the special requirements of different applications (RoHS compliant)
Specifications
| Material Description | Steel Clip |
|---|---|
| Clamp Width | 19 mm |
| Material | Alloy Zinc |
| Remarks | Fastener Offset: 12, Fits Fastener: M10 or 3/8, Clamp Diameter: 28.58, Clamp Thickness: 1.2, CL Clamp to CL Fastener: 28 |
Compatible Equipment
- Generator Sets: 3512E, 3512B, 3516C, G3516C
- Track Loaders: 963K, 826H, 953D, 834H, 824G, 816F, 826G, 963D, 824C, 953K, 973K, 994K, 963, 995, 953, 982, 972
- Cold Planers: PL61, PL72, PM620, PM622, PL87, PL83
- Compactors: CB-534D, CS-533C, CB-334D, CS54B, CS68B, CB-335D, 825K, CP54B, CP56B, CB-564D, CS79B, 824K, CS12, CS11, CS78B, CS56B, CS74B, CS7, C9.3B, C13B, CB10, CS-54B, CS64B
- Engines: C27, C32, C13, C175-16, C18
- Excavators: 336D, 305C CR, 308D, 390F L, 374F, 336D2, 308E, 303C CR, 330D L, 328D LCR, 330C, 336D L, 325B L, 330D, 330 L, 330C L, 336D2 L, 325B, 637K, 637G, 621G, 416E, 3516E, 350 L, 621K, 637E, 336E L, 374F L, 621H, 390F, 416F2, 385C L, 385C, 6015B, 6020B, 3516B, 120 GC, 657G, 3508B, 6060, 365B L, 432, 385B, 365C, 365B, 6015, 305 CR, 345C, 6040, 312C L, 312C, 365C L
- Asphalt Pavers: AP655F, AD45, AP655F L, AD30, AP-600D
- Skid Steer Loaders: 232D, 262C, 226B3, 216B3, 279C, 246C, 226D3, 24, 226B, 236B3
- Motor Graders: 12H, 16H, 140K, 160K, 140H, 12K, 14M, 16, 120H, 16M3, 18, 140 GC, 120, 16M, 14
- Wheel Excavators: IT14G, MD6250, MD6310
- Dozers: D11T, D11N, D10N, D10T2, D5N, D9R, D8L, D6N, D6R III, D6R XL, D6T, D6K2, D7H, D6R, D7R II, D5K LGP, D6M, D6R II, D9N, D4G, D7R, D9L, D3K2 LGP, D8T, D8N, D5K2 XL, D6T LGP, D5M, D8R, D5G, D7E, D3G, D4, D1, D10R, D10, D5K XL, D11, D6R LGP, D9T
- Mini Excavators: 310, 305.5, 307B, 307D, 307, 303.5C, 308, 307E2, 306
- Wheel Loaders: 972L, 928G, 966H, 966L, 972H, 950H, 980H, 938M, 924K, 962G, 950G, 924GZ, 836, 938K, 966F, 972G, 950L, 980G, 966K, 992C, 988H, 986H, 988G, R1300G, R1700G, R2900G, R3000H, R1600H, 950 GC, 988K, 926M, 980, 928HZ, 988F, 962L, 950, R2900 XE, 980L, 966, 924HZ, R1700K, 910, M314
- Off-Highway Trucks: 771D, 789D, 773E, 773D, 793F, 797F, 725, 793D, 793, 730, 798 AC, 770G, 775G, 785D, 773F, 785, 772G, 740, 735, 777, 777E, 773, 796 AC, 794 AC, 777D, 789, 740B, 725C2
