6N-8629 Governor Spring Seat
Cat® spring seat in the governor uses spring tension to control the movement of the governor mechanism, helping regulate machine speed.
Description
The spring seat in the governor holds the governor's control spring in place. The control spring is the key element responsible for adjusting engine speed in response to changing conditions. The spring seat ensures that the spring maintains proper tension and is positioned within the governor mechanism.
Attributes
- Made of durable materials that withstand the mechanical stress and vibration of engine operation.
- Designed to securely hold the control spring while allowing it to move within a certain range.
Applications
The spring seat is located inside the governor group, which is located near the engine throttle.
Specifications
| Overall Length | 34.85 mm (1.372 in) |
|---|---|
| Unique Features | 0 |
| Ferrule Outside Diameter | 17.53 mm (0.69 in) |
| Material | Steel(1E0303) |
| Flange Diameter | 34.93 mm (1.375 in) |
| Flange Thickness | 5.91 mm (0.233 in) |
| Ferrule Inside Diameter | 7.92 mm (0.312 in) |
| Cross Hole | Yes |
Compatible Equipment
- Motor Graders: 16
- Track Loaders: 992, 824C
- Compactors: 814, 815
- Dozers: D7G, D8L, D4E, D9L, D10
- Wheel Loaders: 980, 950, 992C
- Off-Highway Trucks: 773, 777
Additional information
| Machine Model | 16, 773, 777, 814, 815, 824C, 950, 980, 992, 992C, D10, D4E, D7G, D8L, D9L |
|---|---|
| Equipment Type | Wheel Loaders, Track Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors |
| Part Source | Genuine OEM |
