Description
Cat® J Series Adapters offer unmatched manufacturing precision to protect your machine's bucket from damage. Our Ground Engaging Tools (GET) are designed around the inherent characteristics of your Cat equipment to deliver consistently superior protection.
Cat® corner shroud adapters provide excellent corner protection along with all of the added penetration benefits of bucket teeth.
Our adapters are durable and cast from steel, retaining hardness and offering long wear life so your machine delivers the performance you need. Always choose Genuine Cat bucket ground engaging tools to protect your investment.
Features
- J550 right bolt-on corner adapter fits a 60 mm base edge with a 22.5 degree bevel angle
Applications
- Excavator Buckets
Specifications
| Base Edge Thickness Grade | 60 |
|---|---|
| Number of Holes | 0 |
| Corner Stop Angle | 4 |
| Overall Length | 506.3 mm (19.933 in) |
| Attachment Method | Weld-On |
| Bottom Bar Length | 339 mm (13.346 in) |
| Hole Spacing | 0 mm |
| Width | 0 mm (0 in) |
| Bevel Angle | 22.5 |
| Wear or Durability | Standard |
| Wear Material | Standard Optional |
| Machine Model | Excavator |
| Attachments | Weld-On |
| Series | J Series |
| Type | Two Strap |
| Size | J550 |
| Adapter Size | J550 |
Compatible Equipment
- Generator Sets: 3512B
- Excavators: 349F L, 324D L, 330 L, 324D, 329D L, 336, 336D2 L, 336D2 XE, 365C, 345C, 340D2 L, 349E L, 345D L, 365B, 350 L, 345B, 365B L, 352F, 349D L, 349E, 330D2 L, 336D L, 330D2, 330C, 330C L, 336D2 GC, 336F L XE, 340, 345D, 340D L, 349, 333, 345 GC, 350, 352, 355, 326D2 L, 336D2, 349D2, 349D2 L, 349D, 326D2, 329D2 L, 336D, 329D, 329D2
Additional information
| Machine Model | 324D, 324D L, 326D2, 326D2 L, 329D, 329D L, 329D2, 329D2 L, 330 L, 330C, 330C L, 330D2, 330D2 L, 333, 336, 336D, 336D L, 336D2, 336D2 GC, 336D2 L, 336D2 XE, 336F L XE, 340, 340D L, 340D2 L, 345 GC, 345B, 345C, 345D, 345D L, 349, 349D, 349D L, 349D2, 349D2 L, 349E, 349E L, 349F L, 350, 350 L, 3512B, 352, 352F, 355, 365B, 365B L, 365C |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
