Description
Hex flange bolts have a flange cast into the bolt head that acts like a washer, spreading the load over a larger area. Flange bolts come in plain flange or serrated flange configurations. Hex flange bolts are heavy hex head bolts available in fully threaded or partially threaded configurations. Compared to many other screws, hex flange bolts can be fastened faster and more efficiently.
Features
- Provides a tighter seal.
- High strength and corrosion protection.
Applications
Hex flange bolts do not require a separate washer, helping save assembly time.
Specifications
| Thread Size (Diameter × Pitch) | M8x1.25 mm |
|---|---|
| Class or Grade | ISO 898-1 Class 8.8 |
| Thread Size | M8 mm (0 in) |
| Remarks | Thread Length (mm) 18 |
| Locking Feature | None |
| Thread Direction | RH |
| Bolt Length | 40 mm (1.575 in) |
| Bolt Type | Hex Flange Head |
| Coating | Zinc Electroplated (96 Hour Salt Spray Test) |
| Flange Diameter | 17 mm (0.67 in) |
| Handle Length | 18 mm (0.709 in) |
| Hex Size | 10 mm (0.39 in) |
| Material | Alloy Zinc |
Compatible Equipment
- Generator Sets: C4.4, C3.3DE50E0, C4.4DE88E0, C7.1, C3.3DE33E0, C7.1DE200E, 3512B
- Track Loaders: 963K, 953D, 953K, 963, 953, 963D
- Cold Planers: TH360B, PL61
- Compactors: CB1.8, CB1.7, CW-34, CS68B, CS79B, CS-56, CS11, CS-563E, CS56B, CS54B, CP54B, CP56B, CB-44B, CS74B, CB-64B, CB16, CB-66B, CS78B, CW-16, CB-14, 816, 815, 814, CP12 GC, CB2.7, CB2.5, CB2.9, CS12 GC, CS12, CS7, CS-54, CP11 GC, CB10, CB13, CB15, CS64B, CS-54B
- Engines: C6.6, C32
- Excavators: 320D2, 326D2, 329D2, 329D2 L, 330, 326D2 L, 320D, 305, 313 GC, 313, 316 GC, 120 GC, 330D2 L, 323, 336 GC, 320E, 312F, 323D2 L, 320, 320D GC, 326GC, 315F LCR, 320 GC, 312E L, 320D2 L, 330D2, 329E L, 301.6, 323GC, 330GC, 315, 312E, 323D2, 315C, 301.8, 313F LGC, 320D2 GC, 312C, 313D2 GC, 312C L, 326, 416F2, 428F, 302.7CR, 329E, 313F L, 323D L, 335F LCR, 313D2, 432, 335, 318D2 L, 313D2-GC, 320 GX, 315 GC, 313 GX, 312 GX, 316 GX, 303CR, 312 GC, 336, 330 GC, 323 GX, 305 CR, 333 GC, 326 GC, XQP200, 333, 320D L, 318D2, 434F2
- Asphalt Pavers: AP655F, AP-600D, AP655F L
- Skid Steer Loaders: 232D3, 239D3, 226D3, 232D, 236D3, 249D3
- Motor Graders: 140 GC, 120, 316F
- Wheel Excavators: M320, M322D, M315D, IT14G, M317D2, M315GC, M313D, M315, M315D2, M320D2
- Dozers: D4, D5K LGP, D6N, D3K2 LGP, D5K XL, D6K2, D1, D9T, D5K2 XL
- Mini Excavators: 301.7CR, 310, 302CR, 301.5, 307, 308
- Wheel Loaders: 950 GC, 926M, 924K, 924HZ, 950L, 928G, 938K, 966F, 910, M314, 928HZ, 938M, 962L, 924GZ, 950
