635-6501 Connecting Rod Group
Wholesale only · Full payment before shipment · Send your machine nameplate to confirm fitment
Fitment data not listed — send us your machine model or serial number to confirm.
Description
Specifications
| Undercarriage System | HD |
|---|---|
| Wear Sensor | None |
| Track Reinforcement System | Not Applicable |
| Track Bolt Thread | M22 |
| Master Link Type | Press-Fit Master Link |
| Main Bolt Thread | M22 |
| Grease Lubricated Track Type | GLT |
| Seal and Lubrication Type | SALT |
| Pin Length | 245.5 mm (9.665 in) |
| Track Shoe Bolt Hole Spacing B | 140 mm (5.512 in) |
| Rail to Pin Boss Outside Diameter | 36.4 mm (1.433 in) |
| Number of Track Links | 49 |
| Weight | 906.6 kg (1998.71 lb) |
| Rail to Bushing Outside Diameter | 34.4 mm (1.354 in) |
| Bolt Hole Diameter | 23 mm (0.906 in) |
| Track Pitch | 215.9 mm (8.5 in) |
| Rotating Bushing Track | No RBT |
| Link Outside Spacing | 200.8 mm (7.906 in) |
| Number of Links | 49 |
| Link Inside Spacing at Sprocket | 100.7 mm (3.965 in) |
| Link Inside Spacing at Roller | 108.4 mm (4.268 in) |
| Pin Retention System | Press Fit |
| Bushing Outside Diameter | 68 mm (2.677 in) |
| Track Shoe Bolt Hole Spacing C | 190 mm (7.48 in) |
| Link Height | 124 mm (4.882 in) |
| Track Shoe Bolt Hole Spacing A | 76 mm (2.992 in) |
Additional information
| Part Source | Genuine OEM |
|---|
