602-9812 Accumulator Charging Valve
Cat® Standard SAE Port Connection Accumulator Charging Valve
Description
The charging valve, part number 602-9812, is used to regulate the stored pressure in the hydraulic accumulator. Cat valves are manufactured to precise specifications and are durable, reliable, and efficient.
Features
- Steel charging valve
- Fitting Type: SAE -16 STOR Port (1-5/16-12) (2X); SAE -10 STOR Port (7/8-14) (3X); SAE -8 STOR Port (3/4-16) (2X)
- Fluid Type: Mineral-Based Hydraulic Oil 10W
- Maximum Working Pressure: 23000 kPa (3336 psi)
- Maximum Flow: 114 LPM (30.1 GPM)
Applications
Suitable for off-highway trucks. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Connector Type | -16 SAE O-Ring Port (1-5/16-12) (X2); -10 SAE O-Ring Port (7/8-14) (x3); -8 SAE O-Ring Port (3/4-16) (X2) |
|---|---|
| Height | 140 mm (5.50 in) |
| Hex Size | Not Specified mm (Not Specified in) |
| Length | 144 mm (5.69 in) |
| Material | Steel |
| Thread Size | None mm (1-5/16-12 (X2); 7/8-14 (X3); 3/4-16 (X2) in) |
| Type | Oil Charging Valve |
| Width | 141 mm (5.53 in) |
Compatible Equipment
- Off-Highway Trucks: 775G, 772G, 770G, 777, 773, 777E
