5S-4546 Retaining Ring (Snap Ring)

Description

Cat retaining rings (5S-4546) install in machined grooves in housings/bores (internal) or on shafts (external), providing high strength and long service life in a variety of applications. Cat retaining rings are manufactured to precise specifications for durability, reliability and high efficiency. You can count on this Built For It product to help you get more work done.

Features

Retaining rings meet or exceed ANSI, ASTM and DIN requirements.
Retaining Ring Type: Internal Axial
Style: Tapered Bevel
Material: Steel
Outside Diameter: 77.47 mm (3.05 in)
Thickness: 2.36 mm (0.09 in)

Applications

Fits into a groove in a shaft or housing to secure a component or assembly. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.

Specifications

Snap Ring Type	Inner Shaft
Style	Tapered Beveled
Coating	Not Specified
Inside Diameter	Not Specified mm (Not Specified in)
Outside Diameter	77.47 mm (3.05 in)
Thickness	2.36 mm (0.09 in)

Compatible Equipment

Generator Sets: 3406C, 3406B, 3512B, C9, C7.1
Motor Graders: 140G, 140H, 12H, 120
Track Loaders: 816F, 824G, 826G
Compactors: 814, 815, 816
Engines: C32, C7, C13, C27, C18, C12
Dozers: D6G2 LGP, D7H, D6R, D7G, D8R, D6G2 XL, D7R, D7R II, D7G2, D8N, D6G
Excavators: 330B, 330 L, 637E, 637G, 350 L, 3516E
Wheel Loaders: 980, 972G, 980G, 836, 966F, 992C, 988F, R1700 II, 950, 992D, R1300G
Off-Highway Trucks: 773, 773D, 793D, 793, 773E
Skid Steer Loaders: 3126B

Machine Model	120, 12H, 140G, 140H, 3126B, 330 L, 330B, 3406B, 3406C, 350 L, 3512B, 3516E, 637E, 637G, 773, 773D, 773E, 793, 793D, 814, 815, 816, 816F, 824G, 826G, 836, 950, 966F, 972G, 980, 980G, 988F, 992C, 992D, C12, C13, C18, C27, C32, C7, C7.1, C9, D6G, D6G2 LGP, D6G2 XL, D6R, D7G, D7G2, D7H, D7R, D7R II, D8N, D8R, R1300G, R1700 II
Equipment Type	Excavators, Wheel Loaders, Track Loaders, Skid Steer Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors, Engines, Generator Sets
Part Source	Genuine OEM
