5S-0709 1.52 mm Thick Track Line Belleville Sealing Washer
Cat® 1.52 mm Thick Steel Track Line Belleville Sealing Washer
Description
The track line Belleville sealing washer is a component of the track parts that seals the gap between the track master bushing and the master link, and is placed between the shim and the master link. A washer is a thin, flat, ring-shaped piece of metal or plastic with a hole in the center, used to distribute the load of a fastener such as a bolt or screw. Washers can also be used as shims to adjust the distance between two objects or surfaces.
Attributes
- Prevents fasteners from loosening.
- Prevents excessive movement of components.
- Provides high strength and wear resistance.
- Manufactured to exact specifications, built for durability and reliability.
Applications
The track line Belleville sealing washer is used in the tracks of heavy equipment.
Specifications
| Gasket Type | Spring-Conical |
|---|---|
| Track Shoe Type | Moderate Duty, Single Grouser, Trapezoidal |
| Coating | Zinc Phosphate + Oil |
| Inside Diameter | 37.26 mm (1.467 in) |
| Thickness | 1.52 mm (0.06 in) |
| Outside Diameter | 56.67 mm (2.231 in) |
Compatible Equipment
- Track Loaders: 953D
- Excavators: 320B, 315C, 320C, 311B, 329D L, 325D
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
