Description
Cat® grommets are made of high-quality rubber suited to the equipment's environment. They keep wires and cables from contacting metal, protect these components from damage (vibration), and prevent rubbing against surrounding structures (vibration, shock, noise).
The grommet has a rubber flange placed evenly on both sides of the material to hold the rubber in place.
Features
The grommet has a rubber tab placed evenly on both sides of the material to hold the rubber in place.
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Diameter | 19 mm (0.75 in) |
|---|---|
| Groove Width – A | 3 mm (0.12 in) |
| Inside Diameter | 9.5 mm (0.37 in) |
| Length | 9 mm (0.35 in) |
| Material Description | Rubber |
| Outside Diameter | 25 mm (0.98 in) |
Compatible Equipment
- Generator Sets: C9
- Track Loaders: 963, 953, 824C, 834H
- Cold Planers: PM622, PM620, PL87, PL61, PL83
- Engines: C32, C18
- Excavators: 336D, 374D L, 336D2, 320D, 330, 330D L, 6020B, 336D L, 330D, 637G, 657G, 350 L, 365B L, 621H, 416F2, 621G, 365C, 432, 340, 336D2 GC, 336D2 L, 336D2 XE, 320D L, 6030, 315, 6040, 352, 434F2, 385B, 312 GX, 312 GC, 340D2 L, 637E, 365C L, 340D L, 365B, 325
- Asphalt Pavers: AP300F, AP355F
- Skid Steer Loaders: 236B3, 216B3, 24, 226B3, 226B
- Motor Graders: 16M, 120, 14M, 140H, 16, 12K, 120H, 160K, 14, 12H, 16H, 18, 16M3, 140K
- Dozers: D6K2, D6N, D5N, D5K2 XL, D3K2 LGP, D5K LGP, D7G, D4, D5H, D7E, D8T, D9T, D11T, D10T, D5K XL
- Mini Excavators: 307B
- Wheel Loaders: 836, 924HZ, R3000H, R2900G, 992C, 992D, 988H, 986H, 988F, 988G
- Off-Highway Trucks: 797F, 745C, 793F, 796 AC, 785, 789D, 794 AC, 775G, 793, 789, 798 AC, 773, 793D
Additional information
| Machine Model | 120, 120H, 12H, 12K, 14, 140H, 140K, 14M, 16, 160K, 16H, 16M, 16M3, 18, 216B3, 226B, 226B3, 236B3, 24, 307B, 312 GC, 312 GX, 315, 320D, 320D L, 325, 330, 330D, 330D L, 336D, 336D L, 336D2, 336D2 GC, 336D2 L, 336D2 XE, 340, 340D L, 340D2 L, 350 L, 352, 365B, 365B L, 365C, 365C L, 374D L, 385B, 416F2, 432, 434F2, 6020B, 6030, 6040, 621G, 621H, 637E, 637G, 657G, 745C, 773, 775G, 785, 789, 789D, 793, 793D, 793F, 794 AC, 796 AC, 797F, 798 AC, 824C, 834H, 836, 924HZ, 953, 963, 986H, 988F, 988G, 988H, 992C, 992D, AP300F, AP355F, C18, C32, C9, D10T, D11T, D3K2 LGP, D4, D5H, D5K LGP, D5K XL, D5K2 XL, D5N, D6K2, D6N, D7E, D7G, D8T, D9T, PL61, PL83, PL87, PM620, PM622, R2900G, R3000H |
|---|---|
| Equipment Type | Excavators, Mini Excavators, Wheel Loaders, Track Loaders, Skid Steer Loaders, Dozers, Motor Graders, Off-Highway Trucks, Asphalt Pavers, Cold Planers, Engines, Generator Sets |
| Part Source | Genuine OEM |
