5P-8247 3.5 mm Thick Hard Washer
Cat® hard washer designed for 0.625 inch fasteners, preventing the fastener from sinking into the material and distributing the load more evenly.
Fitment data not listed — send us your machine model or serial number to confirm.
Description
Cat bolts form a matched system with mating hardened washers and nuts to produce consistent, high clamping force.
Specifications
| Thickness – 3 | 0.14 in |
|---|---|
| Surface Finish | Phosphate and Oil Coating |
| Inside Diameter | 17 mm (0.669 in) |
| Inside Diameter (ID) – 1 | 0.67 in |
| Hardened | Yes |
| Outside Diameter (OD) – 2 | 1.26 in |
| Outside Diameter | 32 mm (1.26 in) |
| Material | Low Alloy Steel |
| Gasket Type | Flat Washer |
| Fits Bolt Size | M16 mm (5/8 in) |
| Coating | Zinc phosphate + oil provides corrosion protection up to the point of assembly (painting is recommended for exterior applications). Salt spray resistance: 72 hours with no red rust. Coating color – dark gray to black. |
| Thickness | 3.5 mm (0.138 in) |
Additional information
| Part Source | Genuine OEM |
|---|
