Description
Cat drawn cup roller bearings can withstand heavy loads and run smoothly at high speeds. The case-hardened shell serves as the outer bearing raceway, forming lips that mechanically retain the needle rollers, retain lubricant, and prevent external material and contaminants from entering.
Features
- Outside Diameter: 20.638 mm (0.8125 in)
- Inside Diameter: 15.875 mm (0.625 in)
- Height: 15.88 mm (0.625 in)
- Case-hardened outer ring with cage
- Able to withstand high loads, with high hardness
- Supports high rotational speeds
- Smallest cross section among rolling bearings
- One-piece unit for easy handling and installation
Applications
Drawn cup roller bearings are designed to support larger shaft diameters, with the bearing running directly on the shaft. They are most commonly used in applications where the housing bore cannot serve as a raceway. Typical applications for drawn cup roller bearings are general reducer shaft supports, gear pumps, and guide bearings.
Specifications
| Material | Alloy Steel |
|---|---|
| Outside Diameter | 20.638 mm (0.8125 in) |
| Inside Diameter | 15.875 mm (0.625 in) |
| Height | 15.88 mm (1.000 in) |
Compatible Equipment
- Track Loaders: 993, 824G, 826G, 826H, 834H, 816F
- Wheel Loaders: 992K, 966 GC
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
