5J-5794 12-Point Head Bolt
Inch
Wholesale only · Full payment before shipment · Send your machine nameplate to confirm fitment
Description
Cat bolts form a matched system with mating hardened washers and nuts to produce sustained high clamping force
Specifications
| Locking Feature | None |
|---|---|
| Head Width – 5 | 0.75 in |
| Handle Length – 2 | 1.50 in |
| Bolt Overall Length – 3 | 3 1/2 in |
| Head Height – 4 | 0.50 in |
| Thread Direction | RH |
| Thread Size | 0.500 mm (0.02 in) |
| Class or Grade | Cat/ASTM F2882 (170 ksi) |
| Thread Size (Diameter × Pitch) | 1/2×13 mm |
| Bolt Length | 88.9 mm (3.5 in) |
| Bolt Type | 12-Point Head Bolt |
| Coating | Zinc Phosphate + Oil |
| Handle Length | 38.1 mm (1.5 in) |
| Thread | Coarse Thread UNC |
| Thread Size (in – TPI) | 1/2 – 13 in |
Compatible Equipment
- Track Loaders: 953, 963, 824C, 834H
- Cold Planers: TH55-E70, PM-200
- Engines: C15, C18
- Dozers: D8L, D9T
- Excavators: 637E, 350 L
- Wheel Loaders: 980H, 836, 992C, 988F, 988H, R2900G, 980G, 990H
- Off-Highway Trucks: 777D
- Asphalt Pavers: AD30
Additional information
| Machine Model | 350 L, 637E, 777D, 824C, 834H, 836, 953, 963, 980G, 980H, 988F, 988H, 990H, 992C, AD30, C15, C18, D8L, D9T, PM-200, R2900G, TH55-E70 |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Dozers, Off-Highway Trucks, Asphalt Pavers, Cold Planers, Engines |
| Part Source | Genuine OEM |
