Description
Smart Cat® equipment owners choose Genuine Cat filtration products
Protect their machines and the businesses they depend on.
Cat High Efficiency Hydraulic and Transmission Filters enhance contamination control while maintaining excellent dirt-holding capacity. Improved filter media gives our filters higher efficiency, greater capacity and lower pressure drop.
Acrylic beads strictly maintain pleat spacing, preventing bunching and maximizing filtration surface area over the life of the filter. In addition, an integrated seal ensures separation between the clean and dirty sides of the element.
While competitive products may appear to work on your machine, no one else knows your equipment like we do. Cat maintenance products are designed and built by the same company that builds your machine, so you can count on our filter elements to deliver excellent fit and performance every time. Contact MECHSC, or visit catfiltercrossreference.com and search by your competitive product part number, to switch to Cat filters today.
Features
Cat High Efficiency Hydraulic and Transmission Filters provide a higher level of protection, including the following benefits:
- Unique filter media provides superior protection
- Improves debris retention
- Improved collapse resistance
Specifications
| Efficiency Rating | Advanced Efficiency |
|---|---|
| Material | Other Mixed: Metal-Nonmetal |
| Filter Type | Spin-On |
| Length | 154.5 mm (6.083 in) |
| Diameter | 83 mm (3.268 in) |
| Flow Direction | Out-to-In |
| Efficiency Category | Advanced High Efficiency |
Compatible Equipment
- Generator Sets: 3512B
- Motor Graders: 316F
- Mini Excavators: 307D, 307B, 307C, 307
- Excavators: 349F L, 330D L, 345D L, 349E L, 349E L VG, 349E, 349D L, 345D, 345C, 340D L, 352F, 345C L, 340D2 L, 313D2, 315F LCR, 323D L, 312D2 L, 320D L, 330D2, 320C, 336F L, 336D L, 330D2 L, 325C, 311C, 329D L, 336D2 L, 330D, 336D2 GC, 314D CR, 325C L, 320D2 L, 320E, 312C L, 315C, 312D, 325D L, 312C, 336E LN, 328D LCR, 315D L, 320D RR, 336F LN, 320D FM, 324D L, 312D L, 314D LCR, 318D2 L, 330C L, 314C, 336F, 313D, 336F L XE, 336E, 323D2 L, 336D2 XE, 320D2 GC, 320C L, 336E L, 311D LRR, 329E L, 313F L, 312E L, 312D2, 323D2, 324D, 312F, 320D GC, 312E, 325D, 313D2-GC, 330C, 318D2, 320D3, 313D2 GC, 326D L, 311B, 323D, 312D2 GC, 336E LH, 318D L, 329E, 336E H, 335F LCR, 320D, 349D2 L, 349D2, 329D, 320D2, 326D2, 336D2, 308E, 326D2 L, 329D2, 308D, 329D2 L, 336D, 349D
- Skid Steer Loaders: 313D2 LGP
Additional information
| Machine Model | 307, 307B, 307C, 307D, 308D, 308E, 311B, 311C, 311D LRR, 312C, 312C L, 312D, 312D L, 312D2, 312D2 GC, 312D2 L, 312E, 312E L, 312F, 313D, 313D2, 313D2 GC, 313D2 LGP, 313D2-GC, 313F L, 314C, 314D CR, 314D LCR, 315C, 315D L, 315F LCR, 316F, 318D L, 318D2, 318D2 L, 320C, 320C L, 320D, 320D FM, 320D GC, 320D L, 320D RR, 320D2, 320D2 GC, 320D2 L, 320D3, 320E, 323D, 323D L, 323D2, 323D2 L, 324D, 324D L, 325C, 325C L, 325D, 325D L, 326D L, 326D2, 326D2 L, 328D LCR, 329D, 329D L, 329D2, 329D2 L, 329E, 329E L, 330C, 330C L, 330D, 330D L, 330D2, 330D2 L, 335F LCR, 336D, 336D L, 336D2, 336D2 GC, 336D2 L, 336D2 XE, 336E, 336E H, 336E L, 336E LH, 336E LN, 336F, 336F L, 336F L XE, 336F LN, 340D L, 340D2 L, 345C, 345C L, 345D, 345D L, 349D, 349D L, 349D2, 349D2 L, 349E, 349E L, 349E L VG, 349F L, 3512B, 352F |
|---|---|
| Equipment Type | Excavators, Mini Excavators, Skid Steer Loaders, Motor Graders, Generator Sets |
| Part Source | Genuine OEM |
