594-5630 Digital Camera
Cat® 12V Two-Wire Ethernet BroadR-REACH Digital Camera, Wire Length: 1000 mm
Description
Cat cameras (for example, 594-5630) provide a wide horizontal view, giving equipment operators an unobstructed line of sight from inside the vehicle. With Cat repair and replacement parts, heavy-duty equipment can be easily repaired in the field.
Features
- Digital two-wire Ethernet camera with mounting fasteners
- Voltage: 12 VDC
- Connector Type: • 2-Pin Connection (2X)
- Signal: Two-Wire Ethernet BroadR-REACH
- Resolution: Selectable 1280 X 800, 1280 X 720, 1024 X 768, 800 X 480
Applications
Cat cameras are for use with the Work Area Vision System (WAVS) on Cat machines. Refer to your Operation and Maintenance Manual or contact MECHSC for more information. Cat parts work in heavy-duty applications in environments with severe vibration, shock, extreme operating temperature ranges, thermal cycling, thermal shock, moisture, corrosion, and dust.
Specifications
| Connector Type | • 2-Pin Connection (2X) |
|---|---|
| Length | 62 mm (2.44 in) |
| Width | 37 mm (1.46 in) |
| Height | 46 mm (1.81 in) |
| Lead Length | 1000 mm (39.37 in) |
| Voltage | 7-12.6 Volts |
Compatible Equipment
- Excavators: 313 GC, 313, 374, 316 GC, 336, 336 GC, 323GC, 320 GC, 320, 315 GC, 349, 340, 352, 345 GC, 323, 326, 326GC, 330GC, 313 GX, 312 GX, 312 GC, 330 GC, 350, 326 GC, 333 GC, 395, 333, 323 GX, 320 GX, 323 GC, 316 GX, 350MHPU, 315, 320D L, 325, 335, 355, 330, 320D
Additional information
| Machine Model | 312 GC, 312 GX, 313, 313 GC, 313 GX, 315, 315 GC, 316 GC, 316 GX, 320, 320 GC, 320 GX, 320D, 320D L, 323, 323 GC, 323 GX, 323GC, 325, 326, 326 GC, 326GC, 330, 330 GC, 330GC, 333, 333 GC, 335, 336, 336 GC, 340, 345 GC, 349, 350, 350MHPU, 352, 355, 374, 395 |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
