590-2865 Track Assembly
Cat® general duty undercarriage track provides greater traction and stability
Description
A track assembly is formed when track shoes and fasteners secure the track shoes to the link group.
Features
- General Duty tracks are designed to provide an affordable option for machines at the end of their life cycle or with low utilization. The initial price is lower, and they can be used until they fail.
- All Cat® undercarriage is backed by the Undercarriage Guarantee. It is manufactured by Caterpillar, hardened, and quality tested to ensure it meets job site productivity and performance needs.
- Triple grouser track shoes provide less penetration and traction than single grouser track shoes, but offer better turning ability. Triple grouser track shoes are standard on track-type loaders and excavators because these machines require less turning resistance and greater maneuverability.
Specifications
| Seal and Lubrication Type | Sealed |
|---|---|
| Track Reinforcement System | Not Applicable |
| Grease Lubricated Track Type | GLT |
| Track Shoe Width | 600 mm (23.622 in) |
| Abrasion Resistant Material | 0 ARM |
| Track Bolt Thread | M20 |
| Master Link Type | Clamp Master |
| Number of Grousers | Triple |
| Offset | Not Applicable |
| Shear | No |
| Main Bolt Thread | M20 |
| Track Shoe Type | Not Applicable |
| Undercarriage System | HD |
| Hole Type | Slotted |
| Number of Track Links | 45 |
| Wear Sensor | No |
| Pin Retention System | Press Fit |
| Link Inside Spacing at Sprocket | 82.57 mm (3.251 in) |
| Number of Links | 45 |
| Track Pitch | 190 mm (7.48 in) |
| Rotating Bushing Track | No RBT |
| Track Shoe Hole Type | Slotted |
| Bushing Inside Diameter | 58.72 mm (2.312 in) |
Compatible Equipment
- Excavators: 320D3, 320D2 GC, 320D2
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
