562-8115 160S Roller 24 Link Drive Chain
Cat® roller chain for tandem drives connects multiple axles or wheels to transfer power from the engine to the driven wheels
Description
The Cat chain group is a key component in the powertrain system of heavy-duty equipment. Used with tandem drive and modular rear axle drive systems, it transfers more power from the engine to the ground. The chain group transmits power from the final drive sprocket to the wheel spindle.
Features
- Overall Length: 49 Pitches
- Chain Pitch: 50.8 mm (2.00 in)
- Chain Width: 61.3 mm (2.41 in)
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| ANSI No. | 160 |
|---|---|
| Overall Length | 2489.2 mm (98.00 in) |
| Pitch | 50.8 mm (2.00 in) |
| Roller Width | 31.55 mm (1.24 in) |
Compatible Equipment
- Motor Graders: 140K, 140 GC, 12K
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
