Specifications
| Bushing Outside Diameter | 64 mm (2.52 in) |
|---|
| Number of Track Links | 50 |
|---|
| Track Shoe Bolt Hole Spacing A | 72 mm (2.835 in) |
|---|
| Number of Links | 50 |
|---|
| Track Shoe Bolt Hole Spacing C | 179 mm (7.047 in) |
|---|
| Link Inside Spacing at Sprocket | 83 mm (3.268 in) |
|---|
| Pin Length | 230 mm (9.055 in) |
|---|
| Link Height | 115 mm (4.528 in) |
|---|
| Bolt Hole Diameter | 23 mm (0.906 in) |
|---|
| Rail to Bushing Outside Diameter | 32 mm (1.26 in) |
|---|
| Link Inside Spacing at Roller | 103.7 mm (4.083 in) |
|---|
| Link Outside Spacing | 185.3 mm (7.295 in) |
|---|
| Rotating Bushing Track | No RBT |
|---|
| Track Pitch | 202.81 mm (7.985 in) |
|---|
| Track Shoe Bolt Hole Spacing B | 129 mm (5.079 in) |
|---|
| Rail to Pin Boss Outside Diameter | 34.4 mm (1.354 in) |
|---|
| Pin Retention System | Press Fit |
|---|
| Main Bolt Thread | M22 |
|---|
| Seal and Lubrication Type | SALT |
|---|
| Master Link Type | Slip Fit Master |
|---|
| Grease Lubricated Track Type | GLT |
|---|
| Track Reinforcement System | Not Applicable |
|---|
| Track Bolt Thread | M22 |
|---|
| Undercarriage System | GD |
|---|
| Wear Sensor | No |
|---|
Compatible Equipment
- Excavators: 330 GC, 330GC, 333, 330
