Description
Cat® Advansys adapters offer unmatched manufacturing precision to protect your machine bucket from damage. Our bucket G.E.T. is designed around the inherent characteristics of your Cat equipment to deliver consistent, superior protection.
Cat® corner shroud adapters provide excellent corner protection along with all of the added penetration benefits of bucket teeth.
Our adapters are durable and cast from steel that holds its hardness and offers long wear life, so your machine delivers the performance you need. Always choose Genuine Cat bucket protection to protect your investment.
Features
- A80 Right Bolt-On Corner Shroud Adapter for 32 mm Base Edge with 22.5 Degree Bevel Angle
Applications
- Wheel Loader Buckets
Specifications
| Material | Carbon Steel |
|---|---|
| Size | K150 |
| Type | Bolt-On Two Strap |
| Series | Advansys |
| Wear or Durability | Standard |
| Number of Holes | 2 |
| Hole Size | 1-1/4-in Plow Bolt (36.5 mm square) |
| Attachment Method | Bolt-On |
| Bevel Angle | 22.5 |
| Base Edge Thickness Grade | 32 |
| Hole Spacing | 101 mm |
| Overall Length | 369.1 mm (14.531 in) |
| Width | 100.1 mm (3.941 in) |
| Corner Stop Angle | 2 |
| Bottom Bar Length | 0 mm (0 in) |
| Position | RH Corner |
Compatible Equipment
- Track Loaders: 953, 963, 953K, 963K
- Wheel Loaders: 950 GC, 950, 950H, 962L, 950L
