Description
Service part for governor and fuel injection assemblies and magneto drive assemblies on Cat heavy-duty equipment.
Features
- Material: Steel
- Thread Size: 3/4-16
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Ferrule Outside Diameter | 36.25 mm (1.427 in) |
|---|---|
| Flange Thickness | 4 mm (0.15 in) |
| Unique Features | No |
| Ferrule Inside Diameter | 17.48 mm (0.688 in) |
| Type | Flanged Sleeve |
| Height | 22.71 mm (0.894 in) |
| Inside Diameter | 17.48 mm (0.688 in) |
| Overall Length | 23 mm (0.89 in) |
| Material Description | Steel |
| Flange Diameter | 57 mm (2.25 in) |
| Outside Diameter | 57.2 mm (2.251 in) |
| Thread Size | 3/4-16 in |
| Internal Groove | None |
| External Groove | None |
| Cross Hole | None |
Compatible Equipment
- Motor Graders: 140G, 120
- Compactors: 814, 815, 816
- Dozers: D7G, D4E
- Wheel Loaders: 950
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
