Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Features
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
- Coating meets the special requirements of different applications (RoHS compliant).
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Material | Alloy Zinc |
|---|---|
| Material Description | ISO Class 8 or SAE Grade 5 Equivalent |
| Drive Chain | 9.525 mm (0.375 in) |
| Thread Size | No. 10 (.190) mm (0 in) |
| Hole Thread Pitch | 32 |
| Coating | Zinc Electroplated |
| Thread Direction | RH |
| Class or Grade | SAE J995 Grade 5 (120 ksi) |
| Thread Size (Diameter × Pitch) | No. 10 (.190)x32 mm |
| Thickness | 3.175 mm (0.125 in) |
| Nut Model | Hex |
Compatible Equipment
- Generator Sets: 3406B, 3406C, 3512B, 3516C, C9, 3512E, G3516, G3516C, C7.1
- Track Loaders: 992, 990K, 973K, 963D, 824C, 826K, 826G, 953K, 826H, 953, 824G, 963, 834H, 982, 972, 993, 953D, 963K, 816F
- Cold Planers: PM622, PL83, PL87, PM620, PL72, PM-200
- Compactors: 834K, 815, 814, CS-583D, CS-533C, CB-334D, C13B, CB-335D, 816, C9.3B, CB-14B, CS-563E, CB-44B, C-9, C-15, CS-533E
- Engines: C32, C15, C7, C11, C27, C13, C18, C175-16, C12
- Excavators: 320D, 336D2, 374D L, 3456, 3126, 336D, 390F L, 349D2 L, 349D2, 349D, 374F, 390D L, 330D L, 349F L, 374, 3512C, 352, 340, 336E L, 320D L, 330C L, 325B L, 336F, 325D L, 336E LN, 325D, 336D2 L, 320C, 637E, 349E L, 3508B, 3516B, 345C, 349D L, 365C, 390F, 349, 6060, 6020B, 340D2 L, 385C, 312D, 336, 336D L, 330C, 336F L, 336E LH, 336D2 GC, 311D LRR, 325C, 323D L, 324D, 637G, 350 L, 3516E, 349E, 374F L, 385B, 365B, 6030, 314D CR, 312F, 657G, 621H, 336F L XE, 330B, 325C L, 330 L, 324D L, 315D L, 315C, 621G, 345B, 385C L, 345D L, 365B L, 6015, 395, 355, 320B, 340D L, 336E, 312C, 345D, 350, 313F L, 352F, 345C L, 350MHPU, 6040, 336D2 XE, 320D FM, 336F LN, 390D, 345 GC, 314D LCR, 621K, 365C L, 336E H, 312D L, 330D, 385C FS, 6018, 312C L, 325B, 349E L VG, 3101, 6015 FS
- Asphalt Pavers: AD30, AD45, AD63
- Skid Steer Loaders: 3126B, 24, 236
- Motor Graders: 12K, 120H, 160K, 12H, 3606, 14M, 140G, 140K, 140H, 16, 16M, 18, 120, 14, 316F, 349 GC, 16M3, 16H
- Wheel Excavators: MD6310, IT14G, MD6250, MD6200
- Dozers: D10, D11T, D10N, D10T, D10R, D11R, D11, D10T2, D7R II, D4E, D6R III, D6T, D7R, D7H, D9R, D7G, D6M, D6R, D6R II, D8L, D8R, D5H, D3G, D6G2 LGP, D4G, D9T, D7E, D5M, D9L, D5G, D6T LGP, D8, D8N, D8T, D7G2, D9, D7, D6R XL, D6R LGP, D11N, D6G, D9N, D5N, D6G2 XL
- Mini Excavators: 307B, 307
- Wheel Loaders: 972G, 950G, 990H, 972H, 950, 986H, 980G, 980H, 966L, 992C, 988G, 966F, 834, 836, 962G, 950H, 966H, 910, 988H, 950 GC, 988K, R1700 II, RM500B, R1700G, R1600H, 980, R2900G, R1300G, 966, R1700K, 972L, 966K, 992D, 928G, 988F, 980L, R2900 XE, 950L, R3000H, 962L
- Off-Highway Trucks: 794 AC, 773, 773E, 725, 785, 770G, 735, 777D, 777, 777E, 797F, 740 GC, 793F, 745, 772G, 730, 740, 773D, 789, 798 AC, 771D, 7495, 789D, 796 AC, 740B, 785D, 775G, 773F, 793, 793D, 725C2, 745C
