Description
Filter Description:
The transmission system oil filter is an important component that helps maintain transmission fluid quality. The filter contains a filter element made of pleated material that captures and removes dirt, debris and other particles from the transmission fluid. As fluid flows through the filter, the filter element collects these contaminants and prevents them from circulating back into the system, where they could cause transmission damage.
Features
- Withstands extreme temperatures and pressures.
- Bypass valve allows oil to flow through the filter even when the filter is plugged.
- Made of high-strength materials that withstand the harsh conditions of the hydraulic system.
Applications
This oil filter is installed in the hydraulic or transmission system, reduces the risk of mechanical failure, extends transmission system life, and is designed specifically for Cat 924, 924K, 926, 926M, 930, 930K, 930M, 938, 938K and 938M Wheel Loaders.
Specifications
| Filter Type | Cartridge |
|---|---|
| Diameter | 94.2 mm (3.71 in) |
| Length | 215 mm (8.465 in) |
| Width | 101.6 mm (4 in) |
| Internal Thread | 1-1/16-12, 7/16-20, M10X1.5 – 6H |
| Overall Length | 215 mm (8.46 in) |
| Weight | 2.24 kg (4.94 lb) |
Compatible Equipment
- Generator Sets: C7.1
- Wheel Loaders: 926M, 924K, 938K, 938M
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
