Description
Cat Fuel Water Separators are designed to remove virtually all free water and 90% of emulsified water, as well as smaller contaminants, while helping extend the life of fuel filters and injectors.
Features
- 8.8 mm (0.35 in) diameter hose barb
- Standard No. 6 port (speed sensor)
- Thread Size: M89-6 Stub Acme Thread
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Polysulfone Plastic |
|---|---|
| Outside Diameter | 107 mm (4.21 in) |
| Length | 274.6 mm (10.81 in) |
| Housing Outside Diameter | 107 mm |
| Filter Type | Cartridge |
| Housing Length | 274.6 mm (10.811 in) |
Compatible Equipment
- Generator Sets: C7.1
- Motor Graders: 316F, 120, 140 GC
- Track Loaders: 963, 953, 953K, 963K
- Compactors: 816, 815, 814, CS-533E
- Engines: C6.6
- Dozers: D6N
- Excavators: XQP200, 320 GC, 323, 315F LCR, 335F LCR, 320E, 313F L, 320, 312E, 312F, 312E L, 329E L
- Wheel Loaders: 926M, 966F, 938M, 938K, 924K, 950 GC
Additional information
| Machine Model | 120, 140 GC, 312E, 312E L, 312F, 313F L, 315F LCR, 316F, 320, 320 GC, 320E, 323, 329E L, 335F LCR, 814, 815, 816, 924K, 926M, 938K, 938M, 950 GC, 953, 953K, 963, 963K, 966F, C6.6, C7.1, CS-533E, D6N, XQP200 |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Dozers, Motor Graders, Compactors, Engines, Generator Sets |
| Part Source | Genuine OEM |
