Description
The track assembly is formed by bolting track shoes and fasteners to the link group.
Features
- General duty tracks are an affordable option for machines nearing retirement or with low utilization. Their lower initial price allows them to be run until failure. All Cat® undercarriage is backed by the Undercarriage System Guarantee. Manufactured by Caterpillar, they are hardened and quality tested to meet the productivity and performance demands of the work site.
- Extreme Duty track shoes have higher resistance to bending and cracking and withstand abrasive materials better than Moderate Duty track shoes. Extreme Duty track shoes are made of tough alloy steel.
Specifications
| Hole Type | Not Applicable |
|---|---|
| Wear Sensor | No |
| Number of Track Links | 43 |
| Undercarriage System | HD |
| Offset | Not Applicable |
| Track Bolt Thread | 1 |
| Number of Grousers | Single |
| Shear | No |
| Grease Lubricated Track Type | Not Applicable |
| Track Shoe Type | ES |
| Master Link Type | 5 Tooth Master |
| Main Bolt Thread | 1 |
| Abrasion Resistant Material | 0 ARM |
| Track Shoe Width | 685 mm (26.969 in) |
| Track Reinforcement System | Not Applicable |
| Seal and Lubrication Type | SALT |
| Pin Retention System | PPR |
| Track Pitch | 240 mm (9.449 in) |
| Track Shoe Hole Type | Not Applicable |
| Rotating Bushing Track | No RBT |
| Bushing Inside Diameter | 85 mm (3.346 in) |
| Number of Links | 43 |
| Link Inside Spacing at Sprocket | 105 mm (4.134 in) |
Compatible Equipment
- Dozers: D9R, D9T, D9
