Description
Cat hoses are designed to route liquids and gases through machine systems. These hoses are made of quality materials built to withstand the application-specific pressure, vibration resistance and flow requirements of Cat heavy-duty equipment. Cat hydraulic hoses and couplings are tested using some of the most rigorous processes in the industry. Every Cat hose and coupling combination is tested as a system to ensure a perfect fit, maximizing safety and reliability.
The hose is made of a synthetic rubber tube and two layers of textile fiber reinforcement braid. The outer layer is oil- and weather-resistant.
Specifications
| Hose Warning | Improper selection of hose and coupling combinations will void the warranty and may result in serious personal injury or death, property damage, or failure of components and machine systems. Cat® hose assembly products are designed and tested as a system to provide reliable connections that maximize hydraulic system safety and reliability. In addition, properly maintained, appropriate Caterpillar tooling is recommended to ensure hoses are crimped to technical specifications. Using Caterpillar hose with another manufacturer's couplings, or Caterpillar couplings with another manufacturer's hose, may result in unreliable, unsafe, or poorly performing hose assemblies. Caterpillar does not recommend or authorize this practice. For more information, refer to SAE J1273 Section 6.3 and ISO 17165-2 Section 6.3. |
|---|---|
| Bulk Unit of Measure | CM |
| Inside Diameter | 25.4 mm (1 in) |
| Dash Size | -16 in |
| Outside Diameter | 35 mm (1.38 in) |
| Operating Pressure | 2000 kPa (290 psi) |
| Operating Temperature | -40°C to 135°C |
| Pressurization Capability | 8000 psi |
| SAE | SAE 100R6 |
Compatible Equipment
- Motor Graders: 16M, 120, 16, 18, 16M3, 14, 140 GC
- Track Loaders: 990K, 992
- Wheel Excavators: MD6200, MD6310
- Compactors: 834K, CS12 GC, CP11 GC, CP12 GC
- Mini Excavators: 307, 307E2, 308E2
- Excavators: 340, 120 GC, 352, 330, 307E
- Wheel Loaders: 836, 990H, 988K, 834
- Skid Steer Loaders: 239D3, 232D3, 249D3, 226D3
Additional information
| Machine Model | 120, 120 GC, 14, 140 GC, 16, 16M, 16M3, 18, 226D3, 232D3, 239D3, 249D3, 307, 307E, 307E2, 308E2, 330, 340, 352, 834, 834K, 836, 988K, 990H, 990K, 992, CP11 GC, CP12 GC, CS12 GC, MD6200, MD6310 |
|---|---|
| Equipment Type | Excavators, Mini Excavators, Wheel Excavators, Wheel Loaders, Track Loaders, Skid Steer Loaders, Motor Graders, Compactors |
| Part Source | Genuine OEM |
