454-4819 6.35 mm ID Hydraulic Hose
Medium Pressure Hydraulic Hose Assembly
Fitment data not listed — send us your machine model or serial number to confirm.
Description
Conveys high-temperature petroleum-based and water-based hydraulic fluids and lubricating oils in hydraulic systems.
Features
Made with an extra-high-temperature synthetic rubber tube and one layer of high-tensile steel braid reinforcement. The synthetic outer layer is oil-, weather- and abrasion-resistant. These features deliver long life and outstanding reliability.
Recommended Applications:
Suitable for medium-pressure, high-temperature service applications. Coast Guard approved for marine service applications.
Specifications
| Hose Type | 1-Wire Braid Compact Hose |
|---|---|
| Hose Inside Diameter | 6.35 mm (0.25 in) |
| Material | Medium Pressure Hose |
| Hose Warning | Improper selections of hose and coupling combinations will void warranties and may result in serious personal injury or death, property damage, or component and machine system failure. Cat® hose assembly products are designed and tested as a system to achieve a reliable connection, thus maximizing hydraulic system safety and dependability. It is also recommended that appropriate and properly maintained Caterpillar tooling is used to ensure hoses are crimped to specifications. Use of Caterpillar hose with other manufacturer's couplings or the use of Caterpillar couplings with other manufacturer's hose may result in the production of unreliable, unsafe or under-performing hose assemblies. It is not recommended or authorized by Caterpillar. For additional information see SAE J1273 section 6.3 and ISO 17165-2 section 6.3. |
| Overall Length | 238 mm (9.37 in) |
| Weight | 0.209 kg |
Additional information
| Part Source | Genuine OEM |
|---|
