Description
Cat® fastener parts are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Hex head bolts/screws provide extremely strong tapping performance.
Features
- Cat fasteners are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements.
- Cat bolts, nuts and washers are specifically designed to work together as a system to maximize clamping force.
- Coating meets the special requirements of different applications (RoHS compliant).
Applications
Cat bolts form a high-performance system with mating hardened washers and nuts to produce consistent, high clamping force. You can trust Cat fasteners to help you build, maintain or rebuild in most machine and shop applications worldwide.
Specifications
| Thread Direction | RH |
|---|---|
| Locking Feature | None |
| Class or Grade | ISO 898-1 Class 10.9 |
| Thread Size | M12 mm (0 in) |
| Thread Size (Diameter × Pitch) | M12X1.75 mm |
| Bolt Length | 60 mm (2.362 in) |
| Bolt Type | Hex Head Bolt |
| Coating | Zinc Plated |
| Material | STEEL |
| Handle Length | 30 mm (1.181 in) |
Compatible Equipment
- Generator Sets: 3512B
- Excavators: 313 GC, 313, 316 GC, 352, 333, 330GC, 336, 312 GC, 320, 320D3, 326, 336 GC, 333 GC, 326 GC, 323 GC, 320 GC, 330 GC, 323, 315 GC, 313 GX, 312 GX, 340, 315, 323D2 L, 320E, 323GC, 330D2 L, 320D2 L, 330D2, 320D2 GC, 329E L, 329E, 326GC, 323D L, 335F LCR, 315F LCR, 323D2, 320D L, 320D GC, 349, 320D3 GC, 335, 316 GX, 323 GX, 330, 320D2, 320D, 326D2, 326D2 L, 329D2 L, 329D2
- Off-Highway Trucks: 7495
Additional information
| Machine Model | 312 GC, 312 GX, 313, 313 GC, 313 GX, 315, 315 GC, 315F LCR, 316 GC, 316 GX, 320, 320 GC, 320D, 320D GC, 320D L, 320D2, 320D2 GC, 320D2 L, 320D3, 320D3 GC, 320E, 323, 323 GC, 323 GX, 323D L, 323D2, 323D2 L, 323GC, 326, 326 GC, 326D2, 326D2 L, 326GC, 329D2, 329D2 L, 329E, 329E L, 330, 330 GC, 330D2, 330D2 L, 330GC, 333, 333 GC, 335, 335F LCR, 336, 336 GC, 340, 349, 3512B, 352, 7495 |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
