453-3363 Exhaust Gas Water Cooler Bracket
Cat® Steel Exhaust Gas Water Cooler Tube Bracket
Description
The exhaust water cooler bracket helps support another bracket to support the exhaust cooler water line tube leading from the engine oil cooler. A bracket is a component used to provide additional support and increase stability for a mechanical structure or system. It is designed to hold various components securely in place and is bolted to the components, helping to ensure safe and efficient operation. Available in various shapes, positions, and alignments depending on the application.
Features
- Provided with M8 size hex nut.
- Distributes loads and reduces stress concentration, improving overall structural strength.
- Withstands any vibration or movement that may occur during operation.
- Heat resistant, resists deformation at high temperatures.
Applications
The exhaust water cooler bracket is used in the water lines of the engine configuration assembly.
Specifications
| Height | 25.4 mm (1 in) |
|---|---|
| Length | 62.6 mm (2.46 in) |
| Material | Carbon Steel |
| Thickness | 3 mm (0.12 in) |
| Width | 54 mm (2.13 in) |
Compatible Equipment
- Engines: C13
- Excavators: 349F L, 352F, 349, 349E L VG, 352, 349E L, 349E
