Description
Track bushings work together with track pins to hold the individual track links together, and they are part of the sealing arrangement between the link and the bushing.
Features
In a sealed track, there is contact between the internal track pins and bushings, which will result in immediate wear due to friction between the two parts. This significantly increases the internal wear life of the link assembly. The grease-lubricated track link assembly can directly replace the sealed link assembly on Cat Hydraulic Excavators.
Specifications
| End Length | 0 mm (0 in) |
|---|---|
| Bushing Inside Diameter | 99999.99 mm (3937.008 in) |
| End Outside Diameter | 50.6 mm (1.992 in) |
| Bushing Outside Diameter | 50.6 mm (1.992 in) |
| Material | Alloy Steel |
| Main Option | No |
| Bushing Dynamic Characteristics | Rotating |
| Overall Length | 114 mm (4.488 in) |
Compatible Equipment
- Excavators: 313, 313 GC, 313F L, 312D2 L, 311D LRR, 312D2 GC, 313D2, 312D2, 313D2 GC, 312E, 313D2-GC, 314D LCR, 312D L, 315 GC, 313F LGC, 315F LCR, 314D CR, 312E L, 312D, 312F, 315
