Description
The Cat headlight glass group is installed over the headlight to provide the required light distribution pattern based on the glass color.
Features
- Clear, colorless soda-lime tempered lamp glass
- Protects the bulb and socket connection
- Clear and bright
- Provides vibration resistance
- Protects the bulb from dust and debris
- Hard-coated lamp glass minimizes UV damage and prevents scratches
Applications
Widely used across Cat product families where reliable lighting is essential. Designed for harsh working environments. Commonly used in headlights and signal lights.
Specifications
| Material | Glass Ceramic |
|---|---|
| Lens Type | Soda-Lime Type Tempered Glass |
| Lens Color | Clear |
| Width | 141.5 mm (5.58 in) |
| Height | 141.5 mm (5.58 in) |
| Depth | 89 mm (3.51 in) |
Compatible Equipment
- Motor Graders: 140 GC, 16M, 14, 18, 140K, 16M3, 120, 16, 160K, 14M, 12K
- Track Loaders: 982, 972
- Cold Planers: TH360B
- Compactors: CP54B, CS56B, CP56B, CW-34, CS74B, CS79B, CS68B, CS78B, CS54B, CS12, CS11, CS64B, CS-54B
- Compact Track Loaders: 279D3, 299D3
- Excavators: 120 GC, 657G, 428F, 434F2, 432
- Wheel Loaders: 966M, 982M, 972M, 980M, 966 GC
- Asphalt Pavers: AP-600D, AP355F, AP655F L, AP655F, AP300F
- Skid Steer Loaders: 289D3, 246D3, 236D, 232D, 236D3, 279C, 262D3, 232D3, 262C, 272D3 XE, 242D3, 299D3 XE, 259D3, 226D3, 262D, 246C, 239D3, 249D3, 246D, 272D3
Additional information
| Machine Model | 120, 120 GC, 12K, 14, 140 GC, 140K, 14M, 16, 160K, 16M, 16M3, 18, 226D3, 232D, 232D3, 236D, 236D3, 239D3, 242D3, 246C, 246D, 246D3, 249D3, 259D3, 262C, 262D, 262D3, 272D3, 272D3 XE, 279C, 279D3, 289D3, 299D3, 299D3 XE, 428F, 432, 434F2, 657G, 966 GC, 966M, 972, 972M, 980M, 982, 982M, AP-600D, AP300F, AP355F, AP655F, AP655F L, CP54B, CP56B, CS-54B, CS11, CS12, CS54B, CS56B, CS64B, CS68B, CS74B, CS78B, CS79B, CW-34, TH360B |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Compact Track Loaders, Skid Steer Loaders, Motor Graders, Compactors, Asphalt Pavers, Cold Planers |
| Part Source | Genuine OEM |
