Description
Cat® standard-duty parts offer a competitive initial purchase price and an advantageous service life compared with industry standards for the target application.
Attributes
Standard-duty parts are backed by the standard Cat® parts warranty.
Standard-duty parts meet industry expectations for durability and technology.
Applications
Standard-duty parts are designed for moderate and light applications and lower-utilization applications.
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Undercarriage System | GD |
|---|---|
| Track Reinforcement System | Not Applicable |
| Main Bolt Thread | 0.875 |
| Grease Lubricated Track Type | Not Applicable |
| Master Link Type | 5 Tooth Master |
| Seal and Lubrication Type | SALT |
| Track Bolt Thread | 0.875 |
| Track Pitch | 215.9 mm (8.5 in) |
| Bolt Size | 7/8 mm (7/8 in) |
| Number of Track Links | 40 |
| Wear Sensor | No |
| Pin Retention System | Press Fit |
| Rail to Pin Boss Outside Diameter | 48.2 mm (1.898 in) |
| Rail to Bushing Outside Diameter | 41.8 mm (1.646 in) |
| Track Shoe Bolt Hole Spacing A | 63 mm (2.48 in) |
| Track Shoe Bolt Hole Spacing B | 146.1 mm (5.752 in) |
| Link Outside Spacing | 201.2 mm (7.921 in) |
| Bushing Outside Diameter | 79.16 mm (3.117 in) |
| Rotating Bushing Track | No RBT |
| Number of Links | 40 |
| Bolt Hole Diameter | 23.22 mm (0.914 in) |
| Link Height | 139.9 mm (5.508 in) |
| Link Inside Spacing at Roller | 108.9 mm (4.287 in) |
| Link Inside Spacing at Sprocket | 97.2 mm (3.827 in) |
| Track Shoe Bolt Hole Spacing C | 204.1 mm (8.035 in) |
| Pin Length | 276 mm (10.866 in) |
Compatible Equipment
- Dozers: D7R II
