417-4535 10.32 mm ID Standard Duty Shim
The Cat® engine oil line standard duty shim ensures precise alignment, clearance, and vibration damping for optimal performance and service life
Wholesale only · Full payment before shipment · Send your machine nameplate to confirm fitment
Description
The engine oil line standard duty shim is a thin, flat shim used to precisely adjust alignment, spacing, and clearance between components within the engine oil system. It plays an important role in preventing friction, optimizing oil flow, and maintaining proper pressure levels. By absorbing vibration, shims enhance system stability and service life. The shim seals the joint to prevent oil leaks, ensuring continuous lubrication and reducing wear.
Attributes
- Seals joints to prevent oil leaks and component damage.
- Withstands heavy machinery loads and challenging environments.
- Improves machine service life and reliability.
Applications
The standard duty shim helps maintain fluid system balance by preventing disruptions that could lead to uneven oil distribution, pressure fluctuations, or suboptimal lubrication.
Specifications
| Material | Carbon Steel |
|---|---|
| Gasket Type | Flat Plate |
| Outside Diameter | 60 mm (0.875 in) |
| Inside Diameter | 22 mm (0.406 in) |
| Thickness | 4 mm (0.875 in) |
Compatible Equipment
- Motor Graders: 140G, 140H, 12H, 120
- Generator Sets: 3406B
- Track Loaders: 953, 824C, 816F
- Compactors: CS-563E, 814, 816, 815
- Engines: C175-16
- Dozers: D7G, D7G2, D6R, D7R, D6G2 LGP, D5H, D7H, D11N, D6G, D11R, D6G2 XL
- Excavators: 637E, 330 L, 350 L, 330B, 637G
- Wheel Loaders: 966F, 972G, 836, 992C, R1300G
- Off-Highway Trucks: 793F, 794 AC, 793, 796 AC, 797F
Additional information
| Machine Model | 120, 12H, 140G, 140H, 330 L, 330B, 3406B, 350 L, 637E, 637G, 793, 793F, 794 AC, 796 AC, 797F, 814, 815, 816, 816F, 824C, 836, 953, 966F, 972G, 992C, C175-16, CS-563E, D11N, D11R, D5H, D6G, D6G2 LGP, D6G2 XL, D6R, D7G, D7G2, D7H, D7R, R1300G |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors, Engines, Generator Sets |
| Part Source | Genuine OEM |
