Description
3T-3772 is a steel compression spring with a free length of 41.15 mm (1.62 in) and an inside diameter of 13.78 mm (0.54 in).
Cat spring parts come in a variety of strengths and sizes to suit specific applications. Compression springs use a helical design that provides compression and tension as the spring compresses (shortens) when more weight is applied.
Features
- Steel compression spring
- Free Length: 41.15 mm (1.62 in)
- Outside Diameter: 20.62 mm (0.81 in)
- Inside Diameter: 13.78 mm (0.54 in)
- Total Coils: 8.3
- Active Coils: 6.3
- Coil Helix Direction: Right-Hand
- Springs meet or exceed current standards and material grades
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Inside Diameter | 0.54 mm |
|---|---|
| Length | 41.15 mm (1.62 in) |
| Material | Steel |
| Outside Diameter | 20.62 mm (0.81 in) |
| Spring Type | Compression |
Compatible Equipment
- Dozers: D10N, D9R, D8L, D9L, D9N
