Description
Specifications
| Hose Warning | Improper selections of hose and coupling combinations will void warranties and may result in serious personal injury or death, property damage, or component and machine system failure. Cat® hose assembly products are designed and tested as a system to achieve a reliable connection, thus maximizing hydraulic system safety and dependability. It is also recommended that appropriate and properly maintained Caterpillar tooling is used to ensure hoses are crimped to specifications. Use of Caterpillar hose with other manufacturer's couplings or the use of Caterpillar couplings with other manufacturer's hose may result in the production of unreliable, unsafe or under-performing hose assemblies. It is not recommended or authorized by Caterpillar. For additional information see SAE J1273 section 6.3 and ISO 17165-2 section 6.3. |
|---|---|
| Ferrule Inside Diameter | 32.13 mm (1.265 in) |
| Cross Hole | No |
| Unique Features | No |
| Overall Length | 52.3 mm (2.059 in) |
| Ferrule Outside Diameter | 42.88 mm (1.688 in) |
| Material | — |
| Inside Diameter | 32 mm |
Compatible Equipment
- Motor Graders: 16, 140G, 120
- Track Loaders: 953, 992, 963, 824C, 816F
- Compactors: 814, 816, 815
- Dozers: D10, D6R II, D8L, D7R II, D7G, D4E, D6R III, D7H, D7R, D6R, D9L, D5M, D8R, D8N, D6G, D10R
- Wheel Loaders: R1700G, 910, 834, 950H, 950, 966F, 972G, 962G, 992C, 980, 980G, R1300G, R1700 II, 950G, 980H, 966H, 972H, R2900G
- Off-Highway Trucks: 773, 777, 785, 773F
- Asphalt Pavers: AD45, AD30
Additional information
| Machine Model | 120, 140G, 16, 773, 773F, 777, 785, 814, 815, 816, 816F, 824C, 834, 910, 950, 950G, 950H, 953, 962G, 963, 966F, 966H, 972G, 972H, 980, 980G, 980H, 992, 992C, AD30, AD45, D10, D10R, D4E, D5M, D6G, D6R, D6R II, D6R III, D7G, D7H, D7R, D7R II, D8L, D8N, D8R, D9L, R1300G, R1700 II, R1700G, R2900G |
|---|---|
| Equipment Type | Wheel Loaders, Track Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors, Asphalt Pavers |
| Part Source | Genuine OEM |
