Description
The steering cylinder retaining ring is a retaining ring used in the steering system to hold the steering cylinder in place. It is an external retaining ring that fits in a groove or recess on the outer surface of the steering cylinder or its housing, securing the cylinder and preventing the cylinder from moving axially during operation.
Features
- Ensures a tight, reliable fit.
- Able to withstand maximum forces and loads.
- Non-corrosive.
Applications
The steering cylinder retaining ring is a key component of the steering system, ensuring proper positioning and securing of the steering cylinder.
Specifications
| Material | Carbon Steel |
|---|---|
| Shape | Tempered Basic |
| Free Diameter – A | 2.35 in |
| Snap Ring Type | Internal |
| Thickness – B | 0.078 in |
| Material Description | Steel Retaining Ring |
| Remarks | Free Diameter: 59.69, Radial Wall: 4.95, Lug Height: 6.35, Groove Width: 2.18, Groove Diameter: 57.17, Housing Diameter: 53.97 |
| Thickness | 1.98 mm |
| Cross Hole | Yes |
Compatible Equipment
- Motor Graders: 140K, 12H, 140H, 140G, 120H, 12K, 16M, 14M, 160K, 16M3, 120, 16, 18, 14
- Track Loaders: 824G, 826G, 826H
- Cold Planers: PL83, PL87
- Dozers: D11N, D10, D8R, D7R II, D6R, D8N, D6R II, D7E, D8T, D6R XL, D6R LGP, D6T, D8, D7
- Excavators: 3508B
- Wheel Loaders: 966H, 972G, 980G, 966K, 972H, 980H
- Off-Highway Trucks: 789, 785, 777E, 777
Additional information
| Machine Model | 120, 120H, 12H, 12K, 14, 140G, 140H, 140K, 14M, 16, 160K, 16M, 16M3, 18, 3508B, 777, 777E, 785, 789, 824G, 826G, 826H, 966H, 966K, 972G, 972H, 980G, 980H, D10, D11N, D6R, D6R II, D6R LGP, D6R XL, D6T, D7, D7E, D7R II, D8, D8N, D8R, D8T, PL83, PL87 |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Dozers, Motor Graders, Off-Highway Trucks, Cold Planers |
| Part Source | Genuine OEM |
