Description
Rectangular seals and seal rings are ring-shaped seals with a rectangular cross-section. Depending on the needs of the application, the edges may be rounded or not rounded.
Features
Cat® seals and seal rings are made from materials compatible with the fluids, temperatures and pressures in Cat engines and machines. These materials resist wear and extrusion, giving the seals excellent compression set resistance.
Our seals and rings are dimensioned to strictly follow tight tolerances, ensuring they are properly seated in the seal groove with the right seal compression.
Cat sealing systems prevent leaks and contamination of more expensive parts. Genuine Cat seals protect your investment.
Applications
Rectangular seals and seal rings are widely used in a variety of sealing applications on Cat machines and engines.
Specifications
| Material | NBR – Nitrile |
|---|---|
| Material Description | NBR is a general-purpose material with good abrasion and cut resistance. It is suitable for air, engine oil, diesel fuel, coolant/urea, hydraulic oil and automatic transmission fluid applications. Never use with biodiesel. |
| Cross-Section Width | 2 mm (0.08 in) |
| Remarks | Dimensions and material descriptions are for reference only. Color may differ from the image. |
| Cross-Section Height | 4.1 mm (0.16 in) |
| Inside Diameter | 50.8 mm (2 in) |
| Overall Width | 59 mm |
| Overall Length | 59 mm |
Compatible Equipment
- Motor Graders: 140 GC, 120, 12K, 160K, 140H, 140K, 120H, 140G, 12H, 16H
- Track Loaders: 963, 953, 824C, 963D, 953D, 963K, 834H, 953K
- Compactors: CB-24B, CB-34B, CC-34B, CS-563E, CB-334D, CB-335D, CS-583D, CB-36B, CS-533C
- Dozers: D6N, D5N, D5M, D4E, D5H, D4G, D3G, D5G
- Excavators: 120 GC
- Wheel Loaders: 986K
- Off-Highway Trucks: 785, 793, 797F, 789, 770G, 772G, 793F
- Asphalt Pavers: AD63, AD45, AD30
Additional information
| Machine Model | 120, 120 GC, 120H, 12H, 12K, 140 GC, 140G, 140H, 140K, 160K, 16H, 770G, 772G, 785, 789, 793, 793F, 797F, 824C, 834H, 953, 953D, 953K, 963, 963D, 963K, 986K, AD30, AD45, AD63, CB-24B, CB-334D, CB-335D, CB-34B, CB-36B, CC-34B, CS-533C, CS-563E, CS-583D, D3G, D4E, D4G, D5G, D5H, D5M, D5N, D6N |
|---|---|
| Equipment Type | Excavators, Wheel Loaders, Track Loaders, Dozers, Motor Graders, Off-Highway Trucks, Compactors, Asphalt Pavers |
| Part Source | Genuine OEM |
