Description
Specifications
| Thread Direction | RH |
|---|---|
| Class or Grade | See Drawing |
| Pitch | 1.5 mm |
| Thread Size | M16 mm (0 in) |
| Hex Size | 24 mm (0.94 in) |
| Thread Size (Diameter × Pitch) | M16x1.5 mm |
| Thickness | 8 mm (0.315 in) |
| Height | 8 mm (0.31 in) |
| Drive Chain | 24 mm (0.945 in) |
| Nut Model | Hex |
| Material | Carbon Steel |
| Material Description | ISO 898-2 Class 12 hardness |
| Coating | Zinc |
Compatible Equipment
- Dozers: D8R, D8N
- Excavators: 336F L, 336E LH, 336D2 XE, 336F, 336F LN, 336F L XE, 336E H, 434F2, 416F2, 311C, 312C L, 312C, 314C
- Asphalt Pavers: AP355F, AP300F
