3E-5519 5-Pin Connector Plug
Cat® 34.8 mm wide 5-pin connector plug for jump start wiring harness.
Description
Cat Connector Plug Groups establish a pin-and-socket connection system to provide reliable electrical connections in a variety of electrical applications on Cat heavy-duty equipment. Quality suited to equipment requirements and built to meet your expectations.
Features
- Nylon connector plug
- Wire Size: 12-16 AWG
- Contact Type: Spade
- Number of Contacts: 5
- Connector Series: MP630
- Color: Black
- Corrosion resistant
- Easy to connect and disconnect
- ROHS compliant
Applications
Cat connector plug groups use reliable wires between wires or between a wire and equipment. Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Overall Length | 41.3 mm (1.63 in) |
|---|---|
| Overall Height | 31.5 mm (1.24 in) |
| Connector Type | 5 Blades |
| Wire Gauge | 12-16 AWG |
| Overall Width | 34.8 mm (1.37 in) |
| Material | Nylon, 6, 6/12, 6/6 Plastic |
Compatible Equipment
- Generator Sets: C7.1, 3516C, 3512E, G3516C, G3516
- Track Loaders: 994K, 995, 993, 990K, 834H, 992
- Cold Planers: SE50 VT, PM620, PM622
- Compactors: CS12, CB-34B, CB-36B, CB-334D, CC-34B, CB-534D, CS-533C, CB-24B, CB-44B, CS74B, CS56B, CS54B, CP54B, CP56B, CS68B, CS78B, C13B, CS11, CB-335D, CB2.9, CC2.7 GC, CB2.7, CB2.5, CB2.7 GC, CB2.5 GC, CB10, CS64B, CS-54B
- Engines: C32, C27, C175-16, C18
- Excavators: 303, 306E2, 3456, 305, 3126, 308E, 307E, 306E, 3512C, 301.8, 305 CR, 432, 3516E, 657G, 637E, 637G, 6040, 621G, 6020B, 3516B, 301.6, 6030
- Asphalt Pavers: AP300F, AP355F, AP-600D, AP655F
- Skid Steer Loaders: 232D, 262D, 246D, 236D
- Motor Graders: 12K, 140K, 120, 160K, 12H, 140H, 16M, 16H, 3606, 14, 14M, 120H, 140G
- Wheel Excavators: MD6250, MD6310, IT14G, MD6200
- Dozers: D9, D8, D11N, D11T, D10T, D10R, D10T2, D3K2 LGP, D11R, D8T, D8R, D11, D7, D10, D1, D6R, D7R II, D9R, D6G2 XL, D7E, D3G, D5K2 XL, D7G2, D5G, D9T, D6R II, D7R, D6G2 LGP, D6N, D4G, D7G
- Mini Excavators: 302CR, 306.5, 306, 307E2, 301.7CR, 301.5, 305.5 GC, 303.5, 305.5E2, 305.5E
- Wheel Loaders: 988H, 986H, 950G, 924HZ, 966H, 962G, 924GZ, 972G, 980G, 972H, 980H, 906K, R2900G, R1700K, 990H, 988K, R3000H, R1300G, 950H
- Off-Highway Trucks: 777, 798 AC, 789, 797F, 785D, 785, 793D, 794 AC, 735, 777D, 789D, 730, 740, 772G, 770G, 777E, 793F, 773F, 796 AC, 775G, 725, 773E, 793, 773, 773D
