3E-5381 Electric Starting Motor Assembly
24 Volt Heavy Duty Electric Starting Motor
Fitment data not listed — send us your machine model or serial number to confirm.
Description
Cat® starters are built to handle the high current encountered when cranking a Cat engine up to starting speed.
Features
- Positive-engagement shift mechanism ensures precise pinion-to-ring-gear engagement.
- One-piece seamless solenoid housing provides corrosion protection.
- Rotatable drive housing allows flexible mounting.
- Brush holder provides constant spring pressure for even wear.
Reman options available.
Specifications
| Pinion Teeth | 10/11 |
|---|---|
| Marine Certification | None |
| Pinion Pitch | 8/10 |
| Electric Starting and/or Prelube | Electric Start |
| Material | Alloy Aluminum |
| Current | 120 Amps |
| Mount Circumference | 127.0 mm |
| Mounting Size | SAE No. 1 Bell Housing Nose Cone |
| Voltage | 24 Volts |
Additional information
| Part Source | Genuine OEM |
|---|
