Description
The cotter pin is a two-piece pin made from a half-round wire folded in the middle and bent into a loop to form the head. After installation, the legs of the pin can be bent to hold the pin in place. Cotter pins are designed for use with the clevis pins included here, for pin bolt and nut assemblies in general applications, or other types of free-positioned pin assemblies.
Cat® fasteners and hardware are designed for specific applications based on size, strength, clamp load and past performance, information other manufacturers do not have. They are carefully selected to last until machine rebuild or end of life. Non-Cat hardware and fasteners may appear to fit your machine, but no one else knows your equipment the way we do.
Features
- Cat fasteners and hardware are manufactured to precise specifications for durability, reliability and high efficiency
- Strength and Quality – Fasteners meet or exceed ISO, ASTM, ASME and SAE requirements
- Coating meets the special requirements of different applications (RoHS compliant)
Applications
- Cat fasteners and hardware are trusted to build, maintain or repair most machines and shop applications worldwide
Specifications
| Remarks | Overall Length: 19.05, Pin Diameter: 1.5875 |
|---|---|
| Material | Galvanized Steel |
| Wire or Pin Diameter | 1.59 mm (0.063 in) |
| Retaining Pin Type | Cotter Hair |
| Pin Length | 19.05 mm (0.75 in) |
| Size | Steel Cotter Pin mm |
| Pin Diameter – A | 1/16 in |
| Material Description | Steel |
| Cotter Pin End Type | Mitered End |
| Pin Length – B | 3/4 in |
| Pin Type | Cotter Pin |
Compatible Equipment
- Generator Sets: 3512B, 3516C, G3516, C4.4
- Track Loaders: 824C, 992, 953, 953K, 963, 963K, 824G
- Cold Planers: PL83, PL87, PL61, PL72
- Compactors: 816, CB-334D, CB-335D, 815, 814
- Engines: C175-16
- Excavators: 305, 306E, 303C CR, 303.5E2 CR, 305C CR, 305E2 CR, 637E, 3516B, 3508B, 621H, 6020B, 303.5CR, 621K, 301.8, 303CR, 637K, 302.7CR, 320C, 301.6
- Motor Graders: 3606, 140G, 120, 16, 14M
- Wheel Excavators: MD6200
- Dozers: D8, D10T2, D11T, D10R, D11R, D10T, D10, D5N, D9L, D6T, D9T, D6R, D6R II, D6N, D7R II, D6R III, D5H, D7R, D7G2, D7G, D4E, D6T LGP, D9R, D7H, D7E, D8L, D9N, D6M, D6R XL, D8R, D10N, D6R LGP, D6G, D8T, D6G2 XL, D8N, D6G2 LGP, D5M, D11N
- Mini Excavators: 303.5E, 303.5D, 308, 305.5E, 303.5C, 302CR, 301.7CR, 301.5, 305.5, 306, 303.5, 305.5E2, 305E2
- Wheel Loaders: 950, 980G, 992D, 992C, R2900G, 950G, 966F, 966H, 972H, 924GZ, 834, 950 GC, 836, 928G, 950H, 962G, R3000H, 910, 972G, 980
- Off-Highway Trucks: 785, 771D, 777, 773D, 777D, 777E, 773E, 789, 775G, 785D, 773F, 773, 793
