398-8325 Link End Pin
Sleeve Bearing Track Link Split Master Link (High Wear, Right, Pin End)
Description
The split master link of the track link makes it easy to remove and install the track without a master pin and master bushing. The split master link has the same wear life as a regular link, with the same strength and hardness, and is fully serviceable and reusable.
Features
The sleeve bearing track design eliminates friction between the pin and bushing, significantly extending track life and increasing the track resealing interval from 4000 hours to 6000 hours. The track seal after turn improves sealing once the bushings have been turned.
Specifications
| Overall Height | 197 mm (7.756 in) |
|---|---|
| Hole to Rail | 110 mm (4.331 in) |
| Rail to Pin Boss Outside Diameter | 60 mm (2.362 in) |
| Bolt Hole Diameter | 38.1 mm (1.5 in) |
| Pin End Bar Thickness | 57.5 mm (2.264 in) |
| Steel Grade | 1E4146 |
| Track Pin Bore Diameter | 66.37 mm (2.613 in) |
| Track Link Crown Height | 0 mm (0 in) |
| Pin Retention System | PPR |
| Lug Thickness | 0 mm (0 in) |
| Wear Sensor | No |
| UC System – Designed For | Heavy Duty Extended Life |
| Material | Alloy Steel |
| Master Link Type | 1 Tooth Master |
| Main Bolt Thread | M36 |
| Track Pitch | 317.5 mm (12.5 in) |
Compatible Equipment
- Dozers: D11T
