Description
The stick cylinder rod is a component of the hydraulic cylinder system commonly used in heavy machinery and equipment. It is responsible for transmitting the force and motion generated by the hydraulic cylinder to the required mechanism.
Attributes
- Withstands heavy loads and high pressure.
- Durability and corrosion resistance.
Applications
The stick cylinder rod is used to extend and retract the boom, stick, and bucket of the machine. Widely used in Caterpillar 312D, 312E, 312F, 313D, 313F, 314D, 314E, 314F, and 315F excavators.
Specifications
| Diameter | 130 mm (5.12 in) |
|---|---|
| Length | 1618.4 mm (63.72 in) |
| Overall Width | 100 mm (3.94 in) |
| Thread | 1/4-18, 1/8-12 |
| Weight | 65.26 kg (143.87 lb) |
Compatible Equipment
- Excavators: 313D2, 312E, 314D LCR, 313D2 GC, 313F LGC, 312D2, 312D2 L, 312D L, 314D CR, 312F, 312D, 313F L, 312E L, 313D2-GC, 312D2 GC, 315F LCR
- Skid Steer Loaders: 313D2 LGP
