Description
Cat hydraulic pumps (e.g., part number 375-2948) provide the oil flow and pressure needed to operate actuators and motors. Whether a gear pump, a vane pump for higher pressures, or a piston pump, Cat hydraulic pumps are a reliable choice for high-demand hydraulic systems. Durable, high-load bearings and bushings provide high peak power density for flow-on-demand hydraulic system performance. High-performance seals and washers withstand extreme hydraulic pressures and temperatures, reducing leaks and improving reliability.
Cat parts are built to exact specifications for durability, reliable performance, efficiency and environmental friendliness, and are reusable.
Features
- Steel piston pump
- 2-Bolt Mounting, M12 Fasteners
- Drive Shaft Spline Teeth: 15
- Drive Shaft Spline Size: 1 in
- Displacement/Revolution: 45 cc (2.75 cu. in)
- Rotation: Clockwise
- Pressure Port: 1 in, 4 Bolt
- Suction Port: 1-1/2 in, 4 Bolt
- Drain Port: SAE #10 7/8-14 STOR (2X)
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Flange Hole Spacing | 146 mm (5.75 in) |
|---|---|
| Overall Length | 189 mm (7.44 in) |
Compatible Equipment
- Motor Graders: 14, 16, 18, 16M3
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
