Description
The hydraulic fan piston motor, also called a hydraulic fan drive motor, is a hydraulic motor used to drive cooling fans in various applications, especially in machines and machinery. It is commonly used to provide efficient cooling for engines, radiators, and other heat-generating components.
Attributes
- Optimal performance under varying conditions.
- Reduces the effort required of the operator.
Applications
The hydraulic fan piston motor is used to convert hydraulic power into mechanical rotary motion to drive the fan, and is mainly used on Cat D10T track-type tractors.
Specifications
| Flange Hole Spacing | 146 mm (5.75 in) |
|---|---|
| Material | Carbon Steel |
| Overall Length | 253.4 mm (9.98 in) |
| Overall Width | 174 mm (6.85 in) |
| Weight | 21.77 kg (47.89 lb) |
Compatible Equipment
- Dozers: D10T2
