Description
Cat® Advansys Adapters offer unmatched manufacturing precision to protect your machine's bucket from damage. Our Ground Engaging Tools (GET) are designed around the inherent characteristics of your Cat equipment to deliver consistently superior protection.
Cat® two-strap adapters have a lower profile than flush-mount adapters, producing greater penetration and higher productivity.
Our adapters are durable and cast from steel that holds its hardness and offers long wear life, so your machine delivers the performance you need. Always choose Genuine Cat bucket protection to protect your investment.
Features
- A200 center hammerless adapter fits 100 mm base edge with 22.5-degree bevel angle
Applications
- Excavator Buckets
Specifications
| Wear or Durability | Standard |
|---|---|
| Material | Carbon Steel |
| Series | Advansys |
| Size | Advansys 200 |
| Type | Two Strap |
| Bottom Bar Length | 336.5 mm (13.248 in) |
| Width | 220 mm (8.661 in) |
| Number of Holes | 0 |
| Overall Length | 731.1 mm (28.783 in) |
| Attachment Method | Weld-On |
| Bevel Angle | 35 |
| Hole Spacing | 0 mm |
| Base Edge Thickness Grade | 100 |
| Corner Stop Angle | 0 |
| Position | Center |
Compatible Equipment
- Excavators: 374, 390F, 374F L, 395, 6015B, 390F L
