Description
Cat powertrain components must withstand extremely high torque, high shock loads, and frequent direction changes and shifts. Cat designs and manufactures transmission and final drive components with these demands in mind, ultimately improving powertrain durability and performance over the life of the machine. Cat friction discs work with the brake system to provide the critical friction needed to slow, stop, or hold the machine stationary.
Features
- Two-way multiple parallel grooves optimize heat dissipation.
- Hardened steel core reduces spline wear.
- (45) tooth internal spline ensures an accurate OEM fit.
Applications
Refer to your Operation and Maintenance Manual or contact MECHSC for more information.
Specifications
| Material | Non-Band Type Friction Material |
|---|---|
| Inside Diameter | 92.96 mm (3.6598 in) |
| Outside Diameter | 133.4 mm (5.2519 in) |
| Thickness | 4 mm (0.157 in) |
Compatible Equipment
- Wheel Loaders: 924HZ, 924GZ, 928G, 928HZ
Additional information
| Machine Model | |
|---|---|
| Equipment Type | |
| Part Source | Genuine OEM |
